Bioo Panel 2.0
A revolution in biotech
a unique
360 approach
towards nature

USING
NATURE
BY ONLY APPLYING THE NATURAL MICROORGANISMS IN THE SOIL, WITHOUT DAMAGING ANY LIVING BEING

SAVING
WATER
AVOIDING EVAPORATIONS WITH AN UNDERGROUND SENSORIZED IRRIGATION & AN INTERNAL WATER STORAGE

COMPENSATING
HEAT
FROM NEARBY BUILDINGS WITH AN OPTIMIZED MECHANICAL TRANSPIRATION & INSULLATION SYSTEM

GENERATING
ENERGY
FROM THE BREAKING-DOWN OF ORGANIC MATTER BY MICROORGANISMS FROM EARTH

THE FIRST SYSTEM IN THE WORLD
PROVIDING A
RETURN OF THE INVESTMENT
FROM GREEN AREAS
offering
unlimitted configurations

SUB-SOIL

ROOFS

CEILINGS

WALKWAYS
led by a
team of professionals
from installation to maintenance
Unitary
49m
set-up
2
Approximation of number and size of light points on a field supported by Bioo Panels activated during usable dark hours of a park or by movement sensors. The system includes a back-up connection to the grid and a drip irrigation system.

7 m
7 m
6 Small-size light points

7 m
7 m
1 Large-size light point
THE PROCESS IN A NUTSHELL

1. The biological reactor attracts natural electrogenic or electrophilic microorganisms which reproduce inside Bioo´s substrate
2. The microorganisms decompose organic matter into electrons and hydrogen ions.
3. Hydrogen ions get conducted to the air layer inside the panel combining with oxygen and generating water vapor.
4. The microorganisms create a conductive biofilm on top of the lower electrode (anode) and conduct electrons to the circuit, thus generating an electrical current.
ADAPTED
TO ANY FERTILE ECOSYSTEM
As long as there's soil and water, you'll always have the flexibility to install any kind of natural environment on top of the Bioo Panel.
The biobattery has independent irrigation and energy generation depends exclusively on the organic material from the applied substrate in the lower compartment.
.jpg)
BIOLOGICAL BATTERY
Includes a natural substrate after the instllation process.
OPEN
LAYER
Install any natural ecosystem you wish. Designed to allow flexibility and shelter the biological battery.
The energy production depends solely on the organic material in the lower compartment.
